Boxy Minimalist · high rise, pleated, straight and wide through the leg
Pleated Wide-Leg Trouser
SlabPleat
Pro
280 GSM cotton twill, 40 cm waist, 32 cm front rise, 76 cm inseam, 28 cm leg opening, two forward pleats per front, straight fall from the hip
FRONT
BACK
Starting spec — make a sample before you order in bulk.
New to tech packs? Read how to make one, step by step →Fabric
280
GSM · Heavyweight · range 250–320
Cotton twill (medium weight) — 98% cotton / 2% elastane. Piece-dyed, sanded face; enough weight to hold a pleat and hang straight rather than cling
Trim: Pocket bag · 65% polyester / 35% cotton pocketing · 110 GSM
What does GSM mean? Read the fabric weight guide →How it's made
Waistband
Curved waistband, fused, with two belt-width keepers · height: 4 cm · closure: Zip fly, one bar-tacked tab with a hidden hook and bar
Shoulder
N/a shoulder
Pleats
Two forward-facing pleats per front: first 4 cm from the fly edge, second 4 cm outboard of it. Pleats are stitched down 6 cm from the waist seam so they stay closed when worn
Sleeve hem
n/a
Body hem
4 cm turned hem, blind-stitched. Level hems; no break allowance built in — hem to the wearer
Pockets
Two slanted side pockets, 16 cm openings; one welted back pocket (wearer's right) with a button
Side seams
4-thread overlock, pressed open
Stitch density spi
11 stitches per inch
Size chart
Garment laid flat · M is the sample size
Measure
XS
S
M
L
XL
XXL
A
Waist width (flat, relaxed)
± 1 cm
36
38
40
42
44
46
B
Hip width (flat, 20 cm below waist)
± 1 cm
55
57.5
60
62.5
65
67.5
C
Front rise (waist seam to crotch)
± 0.5 cm
30
31
32
33
34
35
D
Back rise (waist seam to crotch)
± 0.5 cm
41
42
43
44
45
46
E
Thigh width (2 cm below crotch)
± 0.5 cm
33
34.5
36
37.5
39
40.5
G
Leg opening (flat)
± 0.5 cm
27
27.5
28
28.5
29
29.5
H
Inseam
± 1 cm
73
74.5
76
77.5
79
80.5
I
Waistband height
± 0.3 cm
4
4
4
4
4
4
Colourways
Charcoal
#3D4145
Bone
#DDD6C6
Deep Brown
#4A3A2E
Trims & notes
• #4 metal zip 16 cm (fly)
• Trouser hook and bar
• 18L button (back pocket)
• Fusible (waistband and fly)
• Pocketing
• Woven label (back waistband)
• The pleats only work at 250 GSM and up. On lighter twill they collapse after one wash and the trouser reads as badly cut rather than pleated.
• Stitch the pleats down 6 cm. An unstitched pleat opens when the wearer sits and never lies flat again.
• Grade the rise by 1 cm only. Rise grades far less than waist, and this is the mistake that makes large sizes look wrong on a fit model.
• Ask the factory for the hem left long, or supply a hemming allowance — a 28 cm leg opening on a short wearer puddles badly.
