Gorpcore · mid rise, straight and full through the thigh, finishing just above the knee
Ripstop Cargo Short
SwitchbackBellows
280 GSM cotton ripstop, 42 cm waist, 31 cm front rise, 24 cm inseam, 28 cm leg opening, zip fly with belt keepers, two bellows thigh pockets with flaps
FRONT
BACK
Free vector flat
No account
The drawing above, front and back, as an editable vector — open it in Illustrator, Figma or Affinity and put your own graphics on it. Measurements aren't on the flat; they're in the tech pack.
Opens your browser's print window — choose "Save as PDF" as the destination.
Starting spec — make a sample before you order in bulk.
New to tech packs? Read how to make one, step by step →Fabric
280
GSM · Heavyweight · range 250–320
Cotton ripstop — 100% cotton. Piece-dyed, garment-washed once, sanded face. Ask for the ripstop grid to be visible but not coarse — a 3 mm grid reads as workwear, a 10 mm grid reads as costume
Trim: Pocket bag · 65% polyester / 35% cotton pocketing · 110 GSM
What does GSM mean? Read the fabric weight guide →How it's made
Waistband
Curved waistband, fused, with five belt keepers · height: 4 cm · closure: Zip fly with a bar-tacked tab, one 20L shank button
Shoulder
N/a shoulder
Sleeve hem
n/a
Body hem
2.5 cm turned hem, twin-needle topstitched. Level; no turn-up built in
Pockets
Two slanted side pockets, 16 cm openings; two bellows cargo pockets on the thigh, 16 x 15 cm face with a 2.2 cm side gusset and a flapped closure on hook-and-loop; one welted back pocket on the wearer's right
Side seams
Flat-felled outseam, 4-thread overlock inseam
Stitch density spi
10 stitches per inch
Size chart
Garment laid flat · M is the sample size
Measure
XS
S
M
L
XL
XXL
A
Waist width (flat, relaxed)
± 1 cm
38
40
42
44
46
48
B
Hip width (flat, 20 cm below waist)
± 1 cm
55
57.5
60
62.5
65
67.5
C
Front rise (waist seam to crotch)
± 0.5 cm
29
30
31
32
33
34
D
Back rise (waist seam to crotch)
± 0.5 cm
39
40
41
42
43
44
E
Thigh width (2 cm below crotch, one leg)
± 0.5 cm
27
28.5
30
31.5
33
34.5
G
Leg opening (flat, one leg)
± 0.5 cm
26
27
28
29
30
31
H
Inseam
± 1 cm
22
23
24
25
26
27
I
Waistband height
± 0.3 cm
4
4
4
4
4
4
Colourways
Dust Khaki
#B2A383
Black
#1A1A1A
Deep Moss
#4C543F
Trims & notes
• #4 metal zip 14 cm (fly)
• 20L shank button (waistband)
• 18L button (back pocket)
• Hook-and-loop 2.5 cm (cargo flaps, ~4 x 12 cm)
• Fusible (waistband, fly, flaps)
• Pocketing
• Woven label (back waistband)
• Care/content label
• The bellows gusset is the one thing to check on the sample. Cut it as a single continuous strip per pocket and press the corners before stitching; a gusset made from three pieces puckers at the corners and no amount of topstitching hides it.
• Specify the hook-and-loop as hook on the flap and loop on the pocket, in that order. Reversed, the hook side faces outward and shreds everything it touches in a wash.
• Garment-wash once, not twice. Cotton ripstop at 280 GSM loses its hand on a second wash and the grid flattens out.
• Ask for a shrinkage test before cutting. Cotton ripstop moves 3-5% on the length, and at a 24 cm inseam a 5% miss moves the hem above the knee.
• Grade the rise by 1 cm, not proportionally. The cargo pocket position is set from the crotch, so a proportional rise grade walks the pocket down the leg at XL and XXL.
