Boxy Minimalist · mid rise, very full through the hip and thigh, gathered into a cuff above the ankle
Nylon Balloon Pant
CubeBalloon
150 GSM washed nylon-cotton poplin, 38 cm elasticated waist, 32 cm front rise, 66 cm inseam, 34 cm thigh collapsing to an 18 cm elasticated cuff
FRONT
BACK
Free vector flat
No account
The drawing above, front and back, as an editable vector — open it in Illustrator, Figma or Affinity and put your own graphics on it. Measurements aren't on the flat; they're in the tech pack.
Opens your browser's print window — choose "Save as PDF" as the destination.
Starting spec — make a sample before you order in bulk.
New to tech packs? Read how to make one, step by step →Fabric
150
GSM · Lightweight · range 130–175
Washed nylon-cotton poplin — 55% nylon / 45% cotton. Garment-washed, soft but still crisp. This is the whole garment: the balloon shape is held by the fabric's body, so a limp substitution turns it into a pair of pyjamas
Trim: Waistband and cuff elastic · Woven elastic · 0 GSM
What does GSM mean? Read the fabric weight guide →How it's made
Waistband
Turned casing with 4 cm woven elastic and an internal flat drawcord · height: 4 cm · closure: Elastic and drawcord only; no fly
Shoulder
N/a shoulder
Sleeve hem
n/a
Body hem
3 cm turned casing with 2 cm woven elastic at each cuff; elastic cut to 72% of the casing length. Level; the cuff gathers the full leg width down to the stated opening
Pockets
Two side-seam pockets, 16 cm openings, cut deep so they do not gape when the hip is this full
Side seams
French seam — at 150 GSM an overlocked seam shows through on a pale colour
Stitch density spi
12 stitches per inch
Size chart
Garment laid flat · M is the sample size
Measure
XS
S
M
L
XL
XXL
A
Waist width (flat, elastic relaxed)
± 1 cm
34
36
38
40
42
44
B
Hip width (flat, 22 cm below waist)
± 1 cm
62
65
68
71
74
77
C
Front rise (waist seam to crotch)
± 0.5 cm
30
31
32
33
34
35
D
Back rise (waist seam to crotch)
± 0.5 cm
42
43
44
45
46
47
E
Thigh width (2 cm below crotch, one leg)
± 0.5 cm
30
32
34
36
38
40
G
Cuff opening (elastic relaxed, one leg)
± 0.5 cm
17
17.5
18
18.5
19
19.5
H
Inseam (to the bottom of the cuff)
± 1 cm
63
64.5
66
67.5
69
70.5
I
Waistband height
± 0.3 cm
4
4
4
4
4
4
K
Leg width at the cuff seam, before gathering
± 1 cm
25
26.5
28
29.5
31
32.5
Colourways
Bone
#E2DCCF
Black
#1C1C1C
Slate Blue
#5C6B7A
Trims & notes
• 4 cm woven elastic (~90 cm, waist)
• 2 cm woven elastic (~2 x 26 cm, cuffs)
• Flat drawcord 1.2 cm (~150 cm)
• Metal eyelets x2
• Pocketing
• Woven label (inside back waist)
• Care/content label
• Give the factory BOTH leg widths: 28 cm at the cuff seam before gathering, and an 18 cm cuff opening relaxed. A single figure gets read as the finished opening and the leg comes back with no volume at all, which is the whole garment gone.
• Specify the elastic as 72% of the casing length, as a ratio and not just a length. State the ratio or the gather will drift across the size run.
• Hold the thigh measurement. 34 cm at 2 cm below the crotch is what makes this a balloon rather than a wide leg, and it is the first number a factory will try to 'balance' down toward the cuff.
• The crotch takes the strain on a full leg. Ask for a 2.5 cm reinforcement bar-tack at the crotch join and a double-stitched inseam for the first 10 cm.
• Sample this in the pale colourway. At 150 GSM a dark seam allowance shadows through, which is why the spec says French seams — check it on bone, not on black.
