Cyber-Y2K · fitted through the body, close sleeve, sits at the hip
Fitted Funnel-Neck Long Sleeve
PixelRib
Pro
240 GSM 2x2 cotton rib, 7 cm funnel neck, 46 cm chest, 62 cm length, set-in sleeve, narrow 9 cm cuff
FRONT
BACK
Starting spec — make a sample before you order in bulk.
New to tech packs? Read how to make one, step by step →Fabric
240
GSM · Heavyweight · range 210–270
2x2 cotton rib — 94% cotton / 6% elastane. Pre-shrunk, mercerised face; recovery is the spec that matters — ask for 90% recovery after 30 minutes of hold
Trim: Self-fabric funnel neck · Same rib as body · 240 GSM
What does GSM mean? Read the fabric weight guide →How it's made
Shoulder
Set-in shoulder — Overlocked with back-neck tape; no drop — the shoulder point sits on the wearer's shoulder
Neck
Funnel neck, self-fabric, doubled and cover-stitched at the join · rib height: 7 cm · topstitch: Cover-stitch 0.6 cm at the body join only; the top edge is a folded self-edge
Sleeve hem
2 cm turned hem, cover-stitched
Body hem
2.5 cm turned hem, cover-stitched. Straight
Side seams
4-thread overlock, 6 mm
Stitch density spi
12 stitches per inch
Size chart
Garment laid flat · M is the sample size
Measure
XS
S
M
L
XL
XXL
A
Body length (HPS to hem)
± 1 cm
59
60.5
62
63.5
65
66.5
B
Chest width (1 cm below armhole, relaxed)
± 1 cm
41
43.5
46
48.5
51
53.5
C
Hem width (relaxed)
± 1 cm
39
41.5
44
46.5
49
51.5
D
Across shoulder (seam to seam)
± 0.5 cm
39
40.5
42
43.5
45
46.5
E
Sleeve length (from shoulder seam)
± 1 cm
59
60.5
62
63.5
65
66.5
F
Sleeve opening (relaxed)
± 0.5 cm
8
8.5
9
9.5
10
10
G
Armhole (straight)
± 0.5 cm
20
21
22
23
24
25
H
Neck width (seam to seam)
± 0.5 cm
15
15.5
16
16.5
17
17.5
I
Front neck drop (HPS)
± 0.3 cm
4.5
4.5
5
5.5
5.5
6
J
Back neck drop (HPS)
± 0.3 cm
2
2
2
2
2
2
O
Funnel neck height
± 0.3 cm
7
7
7
7
7
7
Colourways
Washed Black
#2B2B2B
Bone
#DDD6C6
Deep Burgundy
#5C2A33
Trims & notes
• Back-neck tape 1.2 cm
• Printed neck label
• Care/content label
• All the measurements on this one are RELAXED, not stretched. Rib measures roughly 20% smaller relaxed than it wears — tell the factory explicitly, because a factory measuring stretched will cut it two sizes too big.
• This is deliberately the opposite of the boxy tee: 46 cm chest at M against 58-62 on everything else in the library. Do not let a factory 'correct' it toward their house block.
• Rib grades differently from jersey. Grade the chest by 2.5 cm, not the 3 cm used on the woven and jersey styles.
• Recovery is the whole garment. A cheap rib with poor elastane looks right on the sample and bags at the elbows within a month — ask for a 30-minute hold test before you approve.
